How-To Videos
Learn how to install and troubleshoot Arzel Zoning products with these quick videos. Use the buttons below to access videos about why contractors choose Arzel, and our in-depth training videos.
How to Install the Tubing for a Zoning System - 2:54
Arzel Zoning systems use PVC tubing to connect the dampers to the zone control panel. Contractors get the advantage of installing a zoning system without running low-voltage wiring to each damper. Here's how to connect the tubing, with tips from our experienced technician.
Watch Video
How to Test and Diagnose Solenoids on an Arzel Zoning System - 4:38
When you're troubleshooting an Arzel Zoning system, don't overlook the solenoids. These components are rarely the culprit, but knowing how to test them will really make your life easier if they do have a problem. Here's how to isolate and test the Arzel solenoids.
Watch Video
How to Test and Diagnose Dampers on an Arzel System - 4:48
Watch this video to learn how you can quickly find the issue when there's a problem with damper operation on an Arzel Zoning system. Start by narrowing it down to one zone, then use this process to find the problem component in that zone.
Watch Video
How to Test the Zones in an Arzel Panel - 4:16
Save yourself the trouble of testing every damper! If you suspect a malfunctioning damper or other component, use this method to test each zone on the panel. You'll narrow down the list of possible issues, and save a lot of time on testing dampers and other components.
Watch Video
How to Test the Arzel Pump – Metal Enclosure - 1:59
Arzel's pneumatic pump powers all of our zone dampers. This video shows how to test the pump if you suspect there's an issue. For use with HeatPumPro, MPS, AirBoss, GTPro, and CoolMizer panels that are in our metal enclosure. See the polycarbonate enclosure pump testing video. #hvaczoning #hvactroubleshooting #hvactechnology
Watch Video
How to Test the Pump in Arzel Zoning Control Panels (polycarbonate enclosure) - 1:39
Arzel's pneumatic pump powers all of our zone dampers. This video shows how to test the pump if you suspect there's an issue. For use with HeatPumPro, MPS, AirBoss, and GTPro panels that are in our polycarbonate enclosure. Here's how to test the pump in a metal enclosure. #hvaczoning #hvactroubleshooting #hvactechnology
Watch Video
How to Set Up Modulating Bypass with ModuPASS - 2:22
Most of the time, a properly designed Arzel Zoning system won't need bypass. When you do need bypass, here's how to set up the ModuPASS® modulating bypass system.
Watch Video
Using the HeatPumPro Screen - 2:19
HeatPumPro has a clear LCD display that makes it easy to see what's going on with the control panel. Here's how to find each setting, and what they mean.
Watch Video
Settings on HeatPumPro’s Main Screen - 2:53
Here's a quick overview of all of the settings on HeatPumPro's main screen. The screen tells you exactly what the panel is doing at the time you look at it. Knowing how to interpret this screen makes it easier to troubleshoot the zoning system.
Watch Video
How to Install Arzel’s EzySlide Rectangular Damper - 0:57
Watch Arzel’s technician show you how to install and uninstall the EzySlide Rectangular Damper. The EzySlide Damper uses a cut-in system, which allows for quick and easy installation. A gasket seal prevents air bleed-by and increases the efficiency of your HVAC-zoned system.
Watch Video
How to Install Arzel’s Insertable Dampers - 1:28
Watch Arzel’s technician show you how to install InsertaDamper and EzyFit dampers, including inserting them into the ductwork and running the plenum-rated tubing to connect each damper to the HVAC zone control panel.
Watch Video
How to Install the EzyFit Damper - 1:27
Watch as our technician shows you how to install the EzyFit damper. The main feature of the EzyFit damper is that it folds like a taco, making it very easy to install HVAC zoning anywhere - even if the ductwork is behind drywall. This video provides insight into typical applications, installation tips, and how to get more HVAC zoning help.
Watch Video
How to Install Arzel’s EzySlide Round Damper - 2:07
Watch Arzel’s technician show you how to install and uninstall the EzySlide Round Damper. The EzySlide Damper uses a cut-in system, which allows for quick and easy installation. A gasket seal prevents air bleed-by and increases the efficiency of your HVAC-zoned system. Installation takes less than 2 minutes, which saves a ton of time on a zoning installation.
Watch Video
How to Use the Zone Weighting Feature - 1:22
Arzel’s HeatPumPro and GTPro zone weighting feature allows users to easily control fan speed based on the amount of ductwork being served. This prevents excessive airflow when using multi-stage equipment. The HeatPumPro and GTPro HVAC zoning panels provide the easiest way to set zone weighting.
Watch Video
How to Choose Which HVAC Zoning Damper You Should Use - 2:20
Learn which HVAC zoning damper is best for your unique situation. Arzel’s retrofit dampers fit into more places, so you can add HVAC zoning almost anywhere, even when the ductwork is difficult to access. Our technicians will walk you through many typical applications and show you how to choose your dampers.
Watch Video
Training Options at Arzel Zoning - 1:23
If you're looking for a way to improve your HVAC zoning skills, Arzel offers several training options, both online and in-person! Learn more today.
Watch Video
Our Best Tips for Installing an Arzel Panel - 1:42
Discover easy installation tips for Arzel Zoning panels. Our products come with a top-tier lifetime warranty. Explore more at arzelzoning.com.
Watch Video
How Easy is it to Install Arzel’s Zoning Systems? - 1:45
If you're looking for a zoning system that is easy to install, Arzel's line of zoning products is the perfect choice. Our systems are designed for quick and easy installation, so you can get your home or business up and running quickly.
Watch Video
When Is It Best to Zone or Split Your HVAC? - 2:47
In this video, we talk about the basics of zoning and how contractors can approach a homeowner about it.
Watch Video
How to Install Arzel Dampers from Arzel Zoning - 6:38
Our EzySlide dampers significantly cut down on your install time because they are so easy to install. We also offer options for retrofit applications where ductwork is inaccessible, like the EzyFit and InsertaDamper. Learn how to install all of these innovative dampers, and how to run the tubing that connects them to the zone control panel.
Watch Video
Low-Voltage Troubleshooting in the HVAC Industry - 3:17
Learn the steps for testing the HVAC outputs on an Arzel panel, with simple steps that can also be used for thermostats, relays, contactors, and switches in the HVAC industry.
Watch Video
Fixing Thermostat Problems with Arzel Panels - 2:38
Arzel panels have built-in diagnostics that prevent certain thermostat calls from being served. When that happens, you might see a "-ILL" on your screen. Learn how to understand these exceptions so you can shorten your diagnostic time.
Watch Video
How to Diagnose Arzel Dampers and Pumps - 9:47
Not only are Arzel dampers the easiest to install, but they are also simple to diagnose in the chance of a failure! Learn just how effortless it is to diagnose damper failures in the field, with the help of our Air Diagnostics Demo.
Watch Video
